Hitec HS-5245MG Mighty Mini 2BB MG Servo U HS5245MG/HS5245/5245MG/5245

Hitec HS-5245 Metal Gear Ball Bearing
                  Digital Super Torque Mini Servo with the
          Universal Futaba J, Hitec S, JR and Airtronics Z Connector.
             Suitable for small medium and sport planes, gliders,
                     .30 size helicopters, and cars.


FEATURES: Dual ball bearings.
          Digital and MOSFET amp programmable (see COMMENTS).
          Indirect drive potentiometer for long life.
          Narrow dead band width and high standing torque.


INCLUDES: One Hitec HS-5245 Metal Gear Ball Bearing Digital Super Torque Mini
            Servo with the Universal with, four rubber grommets, four eyelets,
            one star shaped, one arm, and two arm straight nylon servo horns,
            one aluminum servo horn.



SPECS:    Wire color codes: Black-Ground, Red-Power, Yellow-Signal
          Operating speed: 0.15 sec @ 60° at 4.8V
          Torque: 61 oz-in (4.4 kg-cm)
          Weight: 1.12oz (32g)
          Length: 1.27" (32.4mm)
          Width:  0.66" (16.8mm)
          Height: 1.21" (30.8mm)
          Wire length: 12" (305mm) approximate
