Associated 70019 1/10 Trophy Rat Brushless 2WD Off-Road Championship Truck RTR

This is the 1/10 scale Brushless Electric Powered, 2.4GHz Radio Controlled,
Ready to Run Trophy Rat Truck from Team Associated.
**This version requires Battery and Charger.**

FEATURES
Chassis: Low center-of-gravity design, molded composite chassis
with hook and loop battery straps that accomodate NiMH and 2-3S
LiPo packs
Drive: Rear wheel with 81mm CVA driveshafts
Differential: Heavy duty sealed gear type with externally adjustable
V2 slipper clutch
Brushless Motor: Reedy 3300Kv
Radio: XP120 2.4GHz with DVC (Dynamic Vehicle Control) receiver w/
built-in adjustable gyro that allows vehicle stability to be
adjusted to flow with the terrain, enclosed water resistant
receiver box
Steering Servo: Reedy metal-gear high-torque digital
Electronic Speed Control: Reedy SC600-BL water-resistant with high-
current T-plug and LiPo low voltage cut off
Suspension: Fully adjustable geometry with vertical ball ends for
front and rear roll center adjustments
Shocks: V2 12mm big bore coil-over with blue anodized aluminum
bodies
Body: Factory finished, based on the Northrup Fabrication "Trophy
Rat" integrated LED lights, two front and two rear
Tires: High traction racing compound
Wheels: Method wheels with 12mm hex, matte black in color
Caster: Adjustable, caster/toe-in refers to the angle of the
suspension when viewed from the side of the car in relation to the
chassis
Camber: Adjustable, camber refers to the angle of the tops of the
tires from vertical when viewed from front or behind vehicle
Ball Bearings: Fourteen rubber sealed

INCLUDES
Ready to Run Trophy Rat Truck with Brushless Motor, 2.4GHz Radio w/
DVC Receiver, ESC, Trimmed Body w/Head and Tail Lights, and
Instruction Manual

REQUIREMENTS
AA Batteries: Four for transmitter
Battery: 7.4V LiPo with T-plug connector
Battery Charger: Compatible with selected battery
LiPo Charging Bag
Track Equipment

SPECIFICATIONS
Vehicle;
Length: 18.94" (481mm)
Width: 11.1" (282mm)
Height: 7.8" (198mm)
Weight: 4.04lbs (1834g)
Wheelbase: 12.68" (322mm)
Gearbox Ratio: 2.6:1
Battery Box Dimensions: 5.25 x 1.9" (133 x 48mm), battery space
can be lengthened by 2" (51mm) by removing rubber pad
Body;
Length: 18.9" (479mm)
Width: 7.5" (190mm) at rear of cab, widest point
Height: 5.9" (149mm)
