Power HD
POWER HD B4S 444.4 oz / 0.065s Titanium & Steel Gear Brushless Servo
- SKU:
- B4S
- UPC:
- 6929188004003
- Condition:
- New
Description
Torque(6.0V): 21.0 kg-cm (291.6 oz/in)
Torque(7.4V): 25.0 kg-cm (347.2 oz/in)
Torque(8.4V): 32.0 kg-cm (444.4 oz/in)
Speed: 0.085 sec (6.0V) │ 0.075 sec (7.4V)│
Speed: 0.065 sec (8.4V)
Operating Voltage:6.0 ~ 8.4 DC Volts
Weight: 67.0 g (2.36 oz)
Bearing Type:Ball Bearing x 2
Motor Type:Brushless Motor
Gear Type:Titanium & Steel
Operating Temperature:-20℃~60℃
Working frequence:1520μs / 333hz
Size:41.0 x 20.5 x 38.3 mm ( 1.61 x 0.81 x 1.51 in)
