Radiolink PRM-03 Real-time OSD Information Telemetry Module

Radiolink PRM-03 Real-time OSD Information Telemetry Module Get GPS RSSI Voltage(1S-12S) and More on TX, for AT9S Pro&AT10II, Minipix PIXHAWK APM FC, Come with Connect Cables

TWO WORKING MODES - Telemetering the remaining voltage of the equipment when connect with the receiver. Telemetering model's voltage, speed, climb, throttle, longitude, latitude, altitude, GPS, RSSI, flight mode, yaw, roll, pitch, and distance when connect with the supported flight controller. Get real-time information to avoid battery overworking and know the model's flight data clearly.
MICRO DIMENSION - Only 1.06"*0.51" and light weight of 0.21oz make PRM-03 won't become your model's burden.
COMPATIBLE FC - Flight controllers: Mini Pix/PIXHAWK/APM
COMPATIBLE TX&RX - Transmitters: AT10II/AT10/AT9S Pro/AT9S/AT9. Receivers: R12DS, R9DS (Old version receiver: R10DS, R10D, R9D).
WIDE INPUT VOLTAGE RANGE - PRM-03 telemetry module is compatible with 1s-12s battery(3.7~50.4V).


Specifications

Size: 27*13mm (1.06"*0.51")

Weight (with wires): 6g(0.21oz)

Voltage Input Range: 1S~12S LiPo Battery

Control distance: same as the receiver control distance (Maximum range tested in unobstructed areas free of interference and may vary depending on local regulations).

Compatible receiver: R12DS, R9DS (Old version receiver: R10DS, R10D, R9D)

Compatible transmitter: AT10II/AT10/AT9S Pro/AT9S/AT9

Compatible flight controller: Mini Pix/PIXHAWK/TURBO PiX/APM


Package Includes:
PRM-03 x1
Receiver Connect Cable x1
Connect Cable(Mini Pix) x1
Connect Cable(APM) x1
Connect Cable(PIXHAWK) x1
Connect Cable(Engine Battery) x1
