Savox SH-0263MG PLUS Metal Gear Micro Digital DC Servo w/ Soft Start SSR Mode

Savox SH-0263MG micro digital servo is very fast with metal gears and 2 times stored in ball bearings.

A completely redesigned servo with these features

SOFT START : Soft start (protects the servo and the rudder control mechanism when the on-board electronics are switched on)
Function:

The metal transmission ensures durability and long life.
Aluminum middle housing allows for cooler operating temperatures.
Ideal for small aircraft and 450 size helicopters.
2 times stored in bearings

Specifications:
Torque at 4.8 V - 1.8 kg
Torque at 6 V - 2.2 kg
Speed ​​@ 4.8V - 0.13s / 60 degrees
Speed ​​@ 6v - 0.10s / 60 degrees
Dimensions L x W x H (mm): 22.8 x 12.0 x 25.4
Weight: 15.0 g

Specifications
Operating temperature: -10 ° - 50 ° C
Operating current (no load): 60mA @ 4.8V, 80mA @ 6.0V
Continuous Current (Latch): 550mA at 4.8V, 700mA at 6.0V
Quiescent current: 5mA @ 4.8V, 5mA @ 6.0V
Wire length: 250 ± 5 mm
Output gear: 21 teeth
Bearings: 2BB
Operating travel: 90 ° (1000 → 2000 µs)
Neutral position: 1,500 µs
Pulse width range: 700 → 2300 µs
Maximum travel: Appx 150 ° (700 → 2300 µs)
Refresh rate: 240 Hz
Motor type: DC
