Spektrum SPMXSM2600 Firma 800Kv 4-pole Brushless Motor

Key Features
Ideal for Arrma Roller Kits and 1/5 Scale Bashers and Monster Trucks Running 3-8S LiPo Batteries
Low Cog 4-Pole Motor Design
Alloy Steel 8mm Output Shaft

In The Box
Firma 800Kv 4-Pole Brushless Motor

Needed to Complete
160A ESC

The Firma 800Kv brushless motor is a perfect option for Arrma Roller kits and 1/5 scale bashers and monster trucks with a 3-8S LiPo setup. Featuring a low cog 4-pole design, CNC machined aluminum housing, insulated high purity copper windings, high-quality alloy steel 8mm output shaft, and precision bearings for high durability and smooth rotation. Preinstalled with 6.5mm gold plated bullet connectors for easy installation, and perfectly matched for the Firma 160 Smart ESC.

Features
Perfect upgrade for 1/5 scale bashers and monster trucks running on 3-8S LiPo batteries.
High efficiency design
8S LiPo power capable
High-quality 4-pole sintered rotor
6.5mm gold plated bullet connectors
High-quality construction with precision ball bearings and hardened steel 8mm shaft
Safe-D Shaft provides a c-clip locking point for preventing pinion gear slip

Product Specifications
Adjustable Timing No
Application Arrma Roller Kits
Bushing Or Bearing Bearing
Connector Type 6.5mm Bullet
Connector Wire Length 7.48" (190 mm)
Efficiency 87%
Input Voltage 11.1 - 29.6V (3 - 8S)
Maximum Continuous Current 110A
Motor Design Inrunner
Motor Size 5611
Number of Poles 4
Outer Diameter 2.2" (56 mm)
Product Length 5.23" (133 mm)
Product Weight 39.86oz (1130g)
Recommended Speed Control Spektrum Firma 160A Brushless Smart
Resistance .0049 ohms
RPM/Volt (Kv) 12,475 / 15V
Shaft Diameter 0.3" (8 mm)
Shaft Length 0.867" (22 mm)
