Radiolink Wireless Trainer Cord Cable for Airplane Flight Training Works with AT9S/AT9S Pro/AT10/AT10II/T8FB/T8S

Anti-interference - Radiolink AT9S Pro&AT10II with the technology of DSSS&FHSS hybrid dual spread spectrum and T8FB&T8S with the same FHSS, not only increase the control distance and anti-interference ability but also ensures multiplayer competing at the same time and reduces mutual interference.
Safe and wireless for training - The wireless trainer system effectively avoids the unintentional pull which may cause cord dropping. Training becomes safer and more relieved. Even the RC beginners can enjoy the fun of acro flight with the trainer mode on.
Low latency - RadioLink transmitters take only 3ms for all the channels to respond synchronously. Signals are stable and responsive without any delay even have been transmitted twice by both trainee and trainer transmitters, ensuring a better RC experience. It also ensures control distance up to 1900 feet.
Low Consumption：Wireless trainer system ensures stable voltage output as 5V and receiver won’t easily get damaged by high voltage. Meanwhile, the power supply of the coach's transmitter can provide power to the wireless trainer system at the same time with highly efficient power management.
Innovative Dual-Mode Trainer Function - (1)Brand New ALT Mode: The switch only needs to be toggled once and the model will be controlled by coach and trainee, in turn, each time the switch is toggled. (2)Traditional Hold Mode: Keep pushing the trainer switch (SWH) to allow the model controlled by trainee.
FAQ
Q: Is RadioLink wireless trainer cable compatible with transmitters of other brands?
A: Yes. Only if the transmitter has the trainer function and the paired receiver supports PPM signal output, then it's compatible.
Q: What if the trainer function cannot be activated?
A: After the binding of all the primary and secondary TX is done, set the trainer function from INH to OFF. Then toggle the SWH switch to set the corresponding positions to turn on and off the trainer function.
Q: Why secondary TX fails to control when toggling the SWH switch after the trainer function setting is done?
A: 1) Make sure if the binding between the secondary TX and the RX connected to the wireless trainer cable is done with success.
2) Check if the signal output is PPM. If it's RadioLink receivers (R6DS, R6DSM, R12DSM, R8SM, R8EF, R8FM) used, the PPM signal is with red led always on. For the other receivers, please refer to the corresponding user manuals.
Q: Why do I have to keep holding the SWH switch when activating the trainer function?
A: Enter the menu of the primary TX- Basic Menu- Trainer- Mode- Change it as TRIGGER. If it's RadioLink AT9S that you are using and you can’t find this option, please upload the firmware to V1.7.8 or above.
Q: Can the wireless trainer cable be connected with other device?
A: The output voltage of wireless trainer cable is limited as 5V with the power of 200mA. So it only supports receivers and no other device possible.

Package Includes:
Wireless Trainer Cable
