Castle Mamba Micro X2 16.8V ESC w/ 1010-5600Kv Motor Combo

The Castle Creations Mamba Micro X2 is an updated version of the popular Mamba Micro X ESC, now with higher voltage capability, data logging, CRYO-DRIVE technology, waterproof design, and sensored motor support. This combo includes the Mamba Micro X2 ESC paired with the Castle 1010-5600Kv sensored brushless motor.

This system is ideal for 1/14 and 1/16 scale RC vehicles weighing up to 3 lbs and running up to 3S LiPo with the included motor. The sensored 1010-5600Kv motor provides smooth startup, strong torque, and efficient performance.

Features:
- Waterproof Mamba Micro X2 ESC
- Sensored motor capable
- Includes 1010-5600Kv sensored brushless motor
- Input voltage range: 2S–3S LiPo with included motor
- ESC supports up to 4S LiPo, but included motor is recommended for up to 3S LiPo
- CRYO-DRIVE technology for cooler, more efficient operation
- Data logging enabled
- Auxiliary wire functionality for on-the-fly adjustments
- Transmitter programming for common settings
- Programmable with Castle Link USB adapter or B-LINK Bluetooth adapter, sold separately
- Telemetry ready with compatible Futaba systems and Castle S.BUS2 telemetry link, sold separately
- Audible alerts for calibration and error conditions
- Designed and manufactured by Castle Creations

Includes:
- Mamba Micro X2 ESC with 4mm connectors
- Castle 1010-5600Kv sensored motor
- Sensor harness
- Quick start guide
- Castle decals

ESC Specifications:
- Input voltage: 2S–4S LiPo ESC rating
- Recommended input with included motor: 2S–3S LiPo
- BEC: 2A peak, selectable 5.5V or 7.5V, 5.5V default
- Waterproof design
- Proportional brake
- Reversible operation
- Waterproof on/off switch
- ESC size: 41.6mm x 29.4mm x 21.3mm
- ESC weight with wires: 47g / 1.66 oz
- Motor connectors: 4.0mm bullets
- Battery connector required, sold separately

Motor Specifications:
- Motor: Castle 1010-5600Kv sensored brushless motor
- Input voltage: 2S–3S LiPo
- Kv rating: 5600Kv
- Max RPM: 80,000
- Motor length: 59.5mm
- Motor diameter: 28.25mm
- Shaft diameter: 3.17mm / 1/8"
- Shaft length: 15mm
- Motor weight with wires: 46.5g / 5.17 oz
- Mounting holes: M2.5 at 14mm and 16mm, M3 at 19mm
- Includes 4mm male Castle bullet connectors and 210mm sensor wire

Notes:
- Battery connector is not included and must be soldered to the ESC battery leads.
- Castle recommends a high-current connector rated for at least 40 amps.
- The ESC is waterproof but is not intended for operation while fully submerged.
- After running in wet conditions, rinse with fresh water and fully dry the unit.
- Castle Link USB adapter or B-LINK Bluetooth adapter required for advanced programming, sold separately.
