Yeah Racing ESC-1X Tritronic 1X 1/10 Waterproof Brushed 60A ESC

Description:
Aluminum heatsink brushed ESC with a minimal footprint designed for crawlers! Easy adjust settings switching between drive modes and battery voltage cutoff with simple jumper plugs located at the front of the ESC.


Feature:

For: 1/10: Touring Car ( Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank )

Water-proof and dust-proof, suitable for all-weather condition races.

Small size with built-in capacitor module.

Fwd/Rev/Br running mode fits for various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse).

Great current endurance capability.

Great built-in BEC output capacity.

Automatic throttle range calibration, easy to use.

Easy to set the ESC parameters with jumpers.

Multiple protections: Low voltage cut-off protection for battery / Over-heat protection / Throttle signal loss protection.

Aluminium Heat Sink


Specification:


Fwd. Cont. / Peak Current: 60A /360A

Rev. Cont. / Peak Current: 30A /180A

Voltage Range: 2-3S Lipo or 5-9 NiMH

2S Lipo or 6 NiMH

-1/10 Touring Buggy Crawler Short Course Truck 540/ 550 Motor ≥ 12T Or RPM<30000

3S Lipo or 9 NiMH

-1/10 Buggy Crawler Short Course Truck 540/550 Motor  ≥ 35T Or RPM< 20000 (Suggest additional capacitor when use 3S lipo battery)

Resistance: Fwd 0.001£[, Rev 0.002£[

BEC Output: 3A/6V (Linear Mode)

PWM Frequency: 1KHz

Dimension : 36.5*32*18mm

Weight: : 39g

Cooling Fan: Without cooling fan


Include:

Tritronic 1X ESC (1 pc)

Manual
