Power HD
POWER HD GTS-5 HV Brushless Motor 694.4 oz / 0.08 Alum Gear Low Profile Servo
- SKU:
- GTS-5
- UPC:
- 6929188055005
- Condition:
- New
Description
Torque(6.0V): 36.0 kg-cm / (499.9 oz/in)
Torque(7.4V): 42.0 kg-cm / (583.3 oz/in)
Torque(8.4V): 50.0 kg-cm / (694.4 oz/in)
Speed: 0.11 sec (6.0V) │ 0.09 sec (7.4V)
Speed: 0.08 sec (8.4V)
Operating Voltage: 6.0 ~ 8.4 DC Volts
Weight: 63 g (2.22 oz)
Bearing Type: Ball Bearing x 2
Motor Type: Brushless Motor
Gear Type: 7075+Steel
Max current: 7.5A
Operating Temperature: -20℃~60℃
Working frequency: 1520μs / 1666hz
Size: 41.0 x 20.0 x 29.0 mm ( 1.61 x 0.79 x 1.14 in)
