SRT W45 HV Coreless Waterproof Servo for 1/10 Crawler / 1/8 Buggy/Crawler

KEY FEATURES

& Incredible efficiency and low power consumption
& NMB dual main bearings
& Waterproof function
& 25T output shaft
& 1-Year limited warranty

PRODUCT SPECIFICATIONS


type: digital

bearing: dual

motor type: coreless

gear type: metal

gear material: titanium & steel

control system: pulse width control

working frequency: 1520μs / 330hz

operating voltage: dc 6.0-8.4v

operating temperature range: -10 to +60 degree

operating speed (6.0v): 0.20 sec/60 degrees at no load

operating speed (7.4v): 0.19 sec/60 degrees at no load

operating speed (8.4v): 0.18 sec/60 degrees at no load

stall torque (6.0v): 34.0 kg/cm (472.2 oz/in)

stall torque (7.4v): 40.0 kg/cm (555.5 oz/in)

stall torque (8.4v): 45.0 kg/cm (624.9 oz/in)

potentiometer drive: direct drive

dimensions: 40.7x20.5x38.6 mm / 1.60x0.81x1.52 in

weight: 82.5 g (2.91 oz)

connector wire length: jr 360 mm
