SRT T06 HV Digital Waterproof Servo for 1/10 Crawler

KEY FEATURES

& Wide range of application scenarios

& Miniature lightweight design
& Incredible efficiency and low power consumption
& Waterproof funciton
& 1-Year limited warranty

PRODUCT SPECIFICATIONS


type: digital

bearing: dual

motor type: DC

gear type: metal

gear material: copper & alu

control system: pulse width control

working frequency: 1520μs / 330hz

operating voltage: dc 4.8-7.4v

operating temperature range: -10 to +60 degree

operating speed (4.8v): 0.16 sec/60 degrees at no load

operating speed (6.0v): 0.12 sec/60 degrees at no load

operating speed (7.4v): 0.10 sec/60 degrees at no load

stall torque (4.8v): 1.9 kg/cm (26.4 oz/in)

stall torque (6.0v): 2.5 kg/cm (34.7 oz/in)

stall torque (7.4v): 2.8 kg/cm (38.9 oz/in)

potentiometer drive: direct drive

dimensions: 22.5x12.5x24.0 mm / 0.89x0.49x0.94 in

weight: 16.0 g (0.56 oz)

connector wire length: jr 350 mm
